10.1 Inch Touchscreen HD Monitor 4/6ch With BSD Features

YWX-1010 10.1 Inch 6ch Lcd Monitor Comes Equipped With High Resolution And Dvr System. Enjoy Ultimate Safety On All Road Trips; This Perfect Partner Has Got You Covered In Preventing Accidents And Collisions For Good.

Support 4-6channel Input
Supports Video Input From 6 Cameras At The Same Time
Support AHD1080/720 Signal Camera
Support Recording And Video Playback
BSD/Ai Features
With 9- 35V Wide Voltage Power Supply

Technical Specifications

Model	YWX-1010
Screen Size	10.1″
Ratio	16:9
Resolution	1024（W）* R.G.B * 600(H)
TV System	PAL/NTSC
Brightness	600cd/㎡
Contrast	500:1
Active Area	154.08(W) × 85.92(H) mm
Viewing Angle	U/D:85°/85°,R/L:85°/85°
Image Settings	Brightness、Color、Contrast
Video Format	AHD
Mirror Flip	Non-mirror, mirror, flip, mirror flip
Video Channel	Six channel video input
Reverse Function	Single way back (ruler setting function)
Reversing Delayed	0-15s
Scale Function	Two scale ruler and automatic ruler switch
Power Supply	9-35V，DC/<9W
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃

YWX-1010 Touchscreen HD Monitor – Smart 6-Channel Vision for Safer Driving

Stay aware and in control with the YWX-1010 touchscreen HD monitor, specially designed for commercial and industrial vehicle monitoring. This advanced 10.1-inch LCD monitor supports real-time input from up to 6 AHD cameras, offering unmatched visibility, safety, and convenience in all driving environments.

Ultimate Multi-Camera Monitoring System

The YWX-1010 touchscreen HD monitor supports video input from 6 channels at the same time. Whether installed on trucks, buses, agricultural machinery, or RVs, the monitor delivers a full 360° view of your surroundings, minimizing blind spots and ensuring maximum situational awareness.

Crisp AHD 1080P Display & DVR Functionality

Equipped with support for both AHD 1080P and 720P signals, this touchscreen HD monitor provides crystal-clear video quality. The integrated DVR function allows for seamless video recording and playback—perfect for accident documentation, training, or fleet monitoring.

AI-Powered Safety Features

The YWX-1010 is not just a screen—it’s an intelligent safety tool. With built-in BSD (Blind Spot Detection) and AI capabilities, the touchscreen HD monitor helps detect nearby pedestrians or obstacles and provides real-time alerts to prevent collisions.

Key Features of the YWX-1010 Touchscreen HD Monitor

Supports 4–6 video channels simultaneously
AHD 1080P/720P signal compatibility
High-resolution touchscreen HD monitor with DVR
BSD and AI functions for blind spot alerts and obstacle detection
Video playback and recording support
9V–35V wide voltage input for diverse vehicle applications

Built for Harsh Conditions and Demanding Tasks

Designed with durability in mind, the YWX-1010 touchscreen HD monitor is ideal for heavy-duty applications including long-haul trucking, construction vehicles, and passenger transportation. It functions reliably across a wide voltage range and in all weather conditions.

Make the Smart Choice – YWX-1010 Touchscreen HD Monitor

The YWX-1010 touchscreen HD monitor is your ultimate partner in on-road visibility and safety. Combining powerful camera support, AI features, and DVR functionality, it ensures peace of mind for every driver and fleet manager.

Looking to enhance your vehicle with the latest in surveillance and safety? Choose the YWX-1010 touchscreen HD monitor and drive smarter, safer, and with confidence.
