Dc12v Ip68 700 Tvl Side View Camera With Cmos Image Sensor

Make Your Travel Experience With An RV or Motorhome Even More Enjoyable By Equipping It With Side View Backup Cameras! Yuweixin’s Ywx-612 IP68 Camera Models Are The Perfect Way To Navigate Any Vehicle Safely And Easily, Day Or Night. With A 700 TV lines High-Resolution CMOS image Sensor And 35 Ft Night Vision Distance, You Can Rest Assured That These Reliable Devices Will Make Sure All Blind Spots Are Eliminated On Every Journey.

Use 1/3 Cmos Sensor, Support Analog Hd Video 700 Tvl
Waterproof Grade IP68
Support Mirror Switch And Scale Control Function
With Night Vision Function, Infrared Distance Is 10 Meters
It Can Be Mounted On Both Sides Of The Vehicle

Technical Specifications

Image Sensor	1/3 CMOS PC1058K
TV System	NTSC/PAL
Effective Pixels	1920(H)×1080(V)
Sensing Area	4.880mm*3.670mm
Sync. System	Internal
Resolution	700TVL
Minimum Illumination	0.1 Lux (day), 0 Lux (with IR)
Microphone	Optional
IR LED Qty	8PCS
Video Output	1.0 Vp-p/75 Ohm
Scanning System	interlace
AGC	AUTO
Signal to noise ratio	Better than 48dB
White balance	AUTO
Gamma Consumption	0.45
Electronic Shutter	AUTO
Backlight Compensation	AUTO
Material	Alluminum alloy
Power Supply	DC12V
Lens	2.8mm
Lens Angle	115°
Current Drain	65±5mA
Operating Temperature	-20℃-70℃,RH 95% MAX
Storage Temperature	-30℃-80℃,RH 95% MAX

YWX-612 Side View CMOS Camera – Clear Vision & Full Coverage for Safer Driving

Enhance your vehicle’s visibility with the YWX-612 side view CMOS camera, designed for RVs, motorhomes, trucks, and various large vehicles. Whether you’re reversing, changing lanes, or navigating tight spaces, this camera ensures full side monitoring and eliminates dangerous blind spots.

Advanced CMOS Sensor for High-Quality Imaging

Equipped with a high-resolution 1/3 CMOS sensor, the side view CMOS camera captures analog HD video at 700 TV lines. This delivers sharp and clear footage, making it easier to detect surrounding objects and improve overall driving safety, both day and night.

Rugged & Weatherproof Construction

Designed with IP68-rated waterproof housing, the YWX-612 side-view CMOS camera is fully sealed against dust and water. Whether you’re driving through rain, snow, or mud, this camera performs reliably in extreme environments. Its rugged casing also protects against shocks and vibrations.

Key Features of the Side View CMOS Camera

1/3 CMOS Sensor: Captures crisp and detailed analog HD video (700TVL)
IP68 Waterproof Rating: Fully resistant to dust and water intrusion
Night Vision Enabled: Infrared distance up to 10 meters for enhanced visibility
Mirror Switch Function: Allows flexible image orientation adjustment
Scale Control: Enables parking and distance guidance
Dual-Side Installation: Mountable on either side of the vehicle
Wide Application: Perfect for RVs, trucks, buses, and more
Reliable Blind Spot Coverage: Helps prevent side collisions and close calls

Your Ideal Side View CMOS Camera for Any Journey

Make every journey safer and more comfortable with the YWX-612 side view CMOS camera. Whether you’re driving during the day or night, its powerful infrared night vision ensures you never miss a detail. The ability to install it on either side of your vehicle makes it a flexible and reliable choice for any type of vehicle setup.

As a dependable safety enhancement, this side-view CMOS camera provides real-time visuals, assists in tight maneuvers, and offers peace of mind in every driving situation.

Why Choose Yuweixin’s Side View CMOS Camera?

Trusted by vehicle owners and OEM manufacturers alike, Yuweixin brings premium safety solutions with precision engineering. Add the YWX-612 side-view CMOS camera to your setup and ensure you drive with full confidence and clarity on every trip.
