Night Vision 7 Meters Distance IP69k Infrared Truck Camera

IP69K infrared truck camera
Night Vision 7 Meters Distance IP69k Infrared Truck Camera
waterproof IP69K infrared truck camera
ultra slim IP69K infrared truck camera
IP69K infrared truck camera
Night Vision 7 Meters Distance IP69k Infrared Truck Camera
waterproof IP69K infrared truck camera
ultra slim IP69K infrared truck camera

The YWX-402 IP69K infrared truck camera delivers reliable performance for both day and night driving. It’s built-in night vision technology captures real colors and sharp images, while the 7-meter infrared distance ensures drivers maintain a clear view even in low-light conditions. This significantly boosts safety during nighttime journeys.

Engineered with a high-level IP68 waterproof rating, the camera resists rain, splashes, and car washes without losing functionality. To guarantee durability, every unit undergoes long-term high-pressure soaking tests before leaving the factory.

Equipped with a 1.3-megapixel sensor, mirror switching capability, and advanced night vision features, this IP69K infrared truck camera is an excellent safety companion for commercial vehicles.

Technical Specifications

Image Sensor 1/3 CMOS 2083
TV System NTSC/PAL
Effective Pixels 1920(H)*1080(V)
Sensing Area 4.880mmⅹ 3.670mm
Sync. System Internal
Resolution 1080P/720P
Minimum Illumination 0.1 Lux (day), 0 Lux (with IR)
Microphone Optional
IR LED Qty 2PCS
Video Output 1.0 Vp-p/75 Ohm
Scanning System interlace
Material ABS
Signal to noise ratio Better than 48dB
White balance AUTO
Gamma Consumption 0.45
Electronic Shutter AUTO
Backlight Compensation AUTO
Power Supply DC12V
Lens 2.8mm
Lens Angle 125°
Current Drain 65±5mA
Operating Temperature -20℃-70℃,RH 95% MAX
Storage Temperature -30℃-80℃,RH 95% MAX

Reliable Vision for All Conditions

The IP69k infrared truck camera delivers dependable performance in both day and night conditions. Its advanced 1.3-megapixel sensor provides sharp, clear images, allowing drivers to monitor surroundings with confidence. With a 7-meter infrared night vision range, the camera ensures visibility even in complete darkness, improving driving safety for trucks and heavy vehicles on busy roads or construction sites.

Rugged Waterproof Protection

Built for challenging environments, this truck camera achieves the highest IP69k waterproof rating. It resists rain, mud, and high-pressure washes, making it ideal for long-term outdoor use. Each camera undergoes strict high-pressure soaking tests before shipping to guarantee quality. The durable housing protects internal components from water, dust, and extreme weather, ensuring reliable operation in demanding fleet applications.

Enhanced Image Performance

The camera supports mirror switching to adapt to different installation needs. Its high contrast rate, superior flatness, and minimal stitching gaps deliver smooth video and vivid color reproduction. This design allows the camera to display videos, logos, messages, or alerts with exceptional clarity. Drivers benefit from consistent image uniformity, ensuring every detail is visible, even under direct sunlight.

Flexible Applications Across Industries

The IP69k infrared truck camera is widely used in logistics fleets, trailers, buses, agricultural machines, and construction vehicles. Nightclubs, theaters, and event venues also rely on such technology for monitoring and security. Its versatile design supports installation on the rear, side, or front of vehicles, giving operators comprehensive coverage and reducing blind spots.

Safe and Efficient Fleet Operations

High brightness ensures content remains visible in strong light, while infrared technology provides reliable night driving assistance. The camera enhances overall fleet efficiency by reducing accident risks and supporting driver awareness. Businesses benefit from a product that combines durability, performance, and safety, making it an excellent long-term investment for professional transportation needs.
